Overview

Connecting a SMART Board MX series interactive display to power, room computers, guest laptops, input sources, connecting speakers and room control systems

Products

Concepts

  • cables and connectors
  • power
  • network connection
  • Wi-Fi
  • RJ45 jacks
  • Intel Compute Card
  • room computers, guest laptops and other input sources
  • HDMI
  • VGA
  • USB
  • external speakers
  • connector panel
  • iQ appliance
  • SMART PCM8 series OPS PC

Connect the display to power after you install it but before you turn it on for the first time. You can also connect cables for room computers, guest laptops or other input sources as well as for speakers and room control systems.

By installing cables in advance, you make use of connectors that might not be accessible after the display is wall-mounted. You can then run the cables across floors or behind walls as needed.

Warning

Ensure that any cables that cross the floor to the display are properly bundled and marked to avoid a trip hazard.

Connecting the iQ appliance

For more information about installing the iQ appliance in SMART Board MX series interactive displays, see the SBID-MX165, MX175, MX186, MX265, MX275, MX286, MX365, MX375, and MX386 installation instructions (smarttech.com/kb/171274).

Caution

Install the AM50 iQ appliance and Intel Compute Card before you turn on the display for the first time.

Important

If you’re installing an AM50 iQ appliance in a display, make sure the display’s firmware is updated to 1.8.7 or later. The display may not function properly if the display’s firmware is not updated. See Updating firmware for your SMART Board MX.

Connecting power

SBID-MX265

SBID-MX365

SBID-MX275

SBID-MX375

SBID-MX286

SBID-MX386

Connect the supplied power cable from the AC power inlet on the side of the display to a power outlet.

Note

Refer to the display’s specifications for power requirements and power consumption information (see SMART Board MX specifications).

Important

Drivers smart board cable usb devices dongle

Do not use the RJ45 jack on the AM40 iQ appliance to connect to a network.

The SMART Board MX series interactive display require a network connection for downloading software and firmware updates, and a number of the iQ appliance’s apps require a network connection as well. You can connect to a network using one of the RJ45 jacks on the display (pictured) or using a Wi-Fi connection. For more information about the display’s network connection and configuration, see Connecting to a network.

You can also connect a computer to the display’s other RJ45 jack so the display and computer are connected to the same network.

Important

Do not use the RJ45 jack on the SMART PCM8 series OPS PC to connect to a network.

There are three ways to connect the AM50 iQ appliance to a network:

  • Wi-Fi

  • connect an Ethernet cable from a network outlet directly to the AM50 iQ appliance’s RJ45 jack

  • connect an Ethernet cable from a network outlet to the display’s RJ45 IN jack, and then connect another Ethernet cable from the display’s RJ45 OUT jack to the AM50 iQ appliance’s RJ45 jack

Connecting the Intel Compute Card

With the SBID-MX365, SBID-MX375, and SBID-MX386 models, you can insert an Intel Compute Card in the slot on the AM50 iQ appliance to access the card’s Windows 10 operating system from the display.

Important

  • Make sure the Intel Compute Card is inserted before you turn on the display.

Note

By default, the HDMI output extends the Windows desktop, and this can cause display problems in certain configurations. If you experience issues, set the HDMI out to a mirrored desktop rather than the default extended desktop. Right click, select Display settings, and set the secondary display to mirror the first.

Usb Fru Smart Board Cable

Tip

You can connect peripherals, such as a keyboard or mouse, to the Intel Compute Card using the USB receptacles on the iQ appliance.

Connecting the SMART PCM 8 series OPS PC

If a SMART PCM8 series OPS PC is installed in the accessory slot, you can access an embedded Windows 10 experience from the display.

Tip

You can connect peripherals, such as a keyboard or mouse, to the embedded Windows 10 experience using the USB receptacles on the OPS PC.

You can connect cables to the display so that users can connect and use room computers, guest laptops or other devices, such as Blu-ray disc players.

Notes

  • If your display is configured with firmware 2.0.6 (and later), you can configure the HDMI version for each HDMI connector as either HDMI 1.4 or HDMI 2.0. This allows you to connect HDMI 1.4 devices that are incompatible with HDMI 2.0 connectors and would otherwise appear as DVI devices, see HDMI [connector number]-EDID version.

  • For information about configuring connected computers, see Connecting and using computers with your SMART Board MX.

SMART recommends the following varieties of cable:

Cable type

Maximum length

Recommendation

HDMI

23' (7 m)1

Use only certified HDMI cables that have been tested to support the performance standard you require.

See HDMI cables and connectors for more information.

VGA

23' (7 m)

Use VGA cables with all pins in their connectors fully populated and wired.

See VGA cables and connectors for more information.

Stereo 3.5 mm

20' (6 m)

[N/A]

USB

16' (5 m)

Use a USB extender if the distance between the computer and the display is greater than 16' (5 m). For more information, see USB extenders.

For more information about USB cables, see USB cables and connectors.

Using cables that exceed these maximum lengths may produce unexpected results, such as degraded picture quality or degraded USB connectivity.

Connecting to the side connector panel

The side connector panel includes two HDMI video connectors: HDMI 1 and HDMI 2. Both connectors can accommodate an HDMI cable for video and audio, and both support HDMI 2.0.

Notes

  • The USB Type-B connector for touch control is located on the bottom connector panel. See Connecting to the bottom connector panel.

  • You can connect a wireless USB keyboard and mouse to the two USB Type-A connectors.

The bottom connector panel includes a video connector and USB connector:

  • VGA: This connector can accommodate a VGA cable for video.

  • USB Type-B: This connector can accommodate a USB cable for touch control for computers connected to HDMI 1, HDMI 2 or VGA.

Note

Drivers Smart Board Cable USB Devices

When connecting a computer to the VGA connector, use the Stereo 3.5 mm in connector for audio.

Connecting to the front connector panel

In addition to the three sets of video connectors on the side and bottom connector panel, there is one set of computer connectors on the front control panel:

  • HDMI 3: This set of connectors can accommodate a USB cable for touch control and an HDMI cable for video and audio. This input supports HDMI 1.4 with HDCP 1.4.

  • USB Type-B: This connector can accommodate a USB cable for touch control for computers connected to HDMI 3.

Viewing a connected computer or other device’s input

Users can tap the Input button to open the input selection menu. Tap an input source to view the computer or other device’s input on the display. See Connecting and using computers with your SMART Board MX.

The display includes two 10 W speakers, which are designed to provide sound at the front of a room. You can connect external active speakers if you’re providing sound in a larger space. See SMART Audio 400 classroom amplification system for more information.

You can connect external speakers to the display using the stereo 3.5 mm out connector (pictured).

Drivers Smart Board Cable USB Devices

The display also provides a Sony/Philips Digital Interface (S/PDIF) optical out connector. S/PDIF is a digital audio transmission medium. You need an audio receiver that supports S/PDIF to decode this connection to analog for use with external speakers.

Connecting room control systems

A room control system enables users to control a room’s lighting, audio system and, possibly, the display. Some installations may require you to integrate the display with a room control system.

You can use the display’s RS-232 connector to connect a third-party external control system to the display (see Remotely managing your SMART Board MX using RS-232).

Note

Displays are not compatible with centralized remote control systems, such as a universal remote control.

The following diagram and table present the connectors on the display’s connector panel:

No.

Connector

Connects to

Notes

1

HDMI 1.4 out (HDCP-compliant)

External monitor

This connector is HDCP-encrypted HDMI.

Note

HDMI out is an optional feature. Contact your authorized SMART reseller (smarttech.com/where) for further ordering instructions.

2

USB 2.0 Type-A connector

USB drives and other devices

Connect a USB drive to update the display’s firmware.

Note

If troubleshooting an issue with the display, connect a USB mouse to navigate the display’s on-screen menu.

3

USB 2.0 Type-A connector

USB drives and other devices

Connect USB drives and other devices that you want to use with the currently selected input source.

4

HDMI 1 2.0 in

HDMI 1 input (video and audio)

See Connecting cables for room computers, guest laptops and other input sources.

5

HDMI 2 2.0 in

HDMI 2 input (video and audio)

See Connecting cables for room computers, guest laptops and other input sources.

6

RJ45 (×2)

Network

See Connecting to a network.

The following diagram and table present the connectors on the display’s bottom connector panel:

No.

Connector

Connects to

Notes

1

USB 2.0 Type-B

HDMI 1, HDMI 2 or VGA input (touch)

See Connecting cables for room computers, guest laptops and other input sources.

2

RS-232

Room control system

See Remotely managing your SMART Board MX using RS-232.

3

Stereo 3.5 mm out

External speakers or audio system

See Connecting external speakers.

4

S/PDIF out

Optical digital audio output

See Connecting external speakers.

5

Stereo 3.5 mm in

VGA input (audio)

See Connecting cables for room computers, guest laptops and other input sources.

6

VGA in

VGA input (video)

See Connecting cables for room computers, guest laptops and other input sources.

The following diagram and table present the connectors on the display’s front connector panel:

No.

Name

Procedure

1

USB 2.0 Type-A connector

Connect USB drives and other devices that you want to use with the currently selected input source.

2

USB 2.0 Type-A connector

Connect a USB drive to update the display’s firmware.

3

USB 2.0 Type-B connector

Connect a USB cable to the display and computer to provide touch control of the computer connected to HDMI 3.

4

HDMI 3 input connector

Connect a computer or other input source to the display (see Viewing a connected computer’s input).

Other connectors

There are additional connectors on the bottom of the display (see Installing your SMART Board MX on a wall and Remotely managing your SMART Board MX using RS-232).

Drivers Smart Board Cable Usb Devices Adapter

DevicesAM40 iQ appliance

This diagram and table describe the connectors on the AM40 iQ appliance:

No.

Connector

Connects to

Notes

1

LED

[N/A]

LED lights green when the iQ appliance is inserted in the accessory slot and turned on.

2

Micro SD

[N/A]

This connector is a service port.

3

HDMI out

[N/A]

Do not use. See Side connector panel.

4

USB Type-A (×2)

Supported peripherals

[N/A]

5

RJ45 (AM40 iQ appliance)

[N/A]

Do not use this connector. Use the connectors on the display instead. See Connecting to a network.

6

Eject button

[N/A]

This button ejects the Intel Compute Card.

See Ejecting the Intel Compute Card.

Drivers Smart Board Cable Usb Devices Wireless

AM50 iQ appliance

This diagram and table describe the connectors on the AM50 iQ appliance:

No.

Connector

Connects to

Notes

1

Eject button

[N/A]

This button ejects the Intel Compute Card.

See Ejecting the Intel Compute Card.

2

Intel Compute Card

[N/A]

[N/A]

3

RJ45 NetworkUse this connector to connect the AM50 iQ appliance to a network. See AM50 iQ appliance.

4

HDMI out

[N/A]

Do not use. See Side connector panel.

5

USB Type-A

(CC)

Supported peripherals

Supported USB devices connected to this receptacle are available in the Windows 10 operating system.

See Using Input.

6

USB Type-A

(iQ)

Supported peripherals

Supported USB devices connected connected to this receptacle are available to the iQ experience.

See Connecting power, cables and devices to your SMART Board MX.

7

Power button and LED

[N/A]

LED lights when the appliance is inserted in the accessory slot and turned on.

Press the Power button to start Windows 10 on the Intel Compute Card.

8

Lock and Eject LEDs

[N/A]

The Lock LED lights when the AM50 appliance shouldn’t be removed from the display.

The Eject LED lights when it is safe to remove the appliance from the display. See Ejecting the Intel Compute Card.

Not pictured

9

Intel Compute Card label[N/A]

The label for the Intel Compute Card. The label is titled “Assembly, PC, AM50”.

10

iQ appliance (AM50) label[N/A]

The label for the AM50 appliance. The label is titled “Model / AM50”.

The following diagram and table present the connectors on the optional SMART OPS PC module:

No.

Connector

Connects to

Notes

1

USB Type-C

Supported USB drives, peripherals, and other devices

See USB cables and connectors.

2

USB 2.0 Type-A (×2)

Supported USB drives, peripherals, and other devices

See USB cables and connectors.

3

USB 3.0 Type-A (×2)

Supported USB drives, peripherals, and other devices

See USB cables and connectors.

4

RJ45

[N/A]

The OPS PC module uses the display’s network connection (if available), so you typically don’t need to connect the OPS PC module directly to a network.

5

HDMI out

External display

See HDMI cables and connectors.

6

Stereo 3.5 mm out

External speakers or headphones

[N/A]

7

Stereo 3.5 mm in

Microphone

[N/A]
