Qsi camerasQsi camera astrophotography

QSI cooled CCD cameras are designed to produce high quality images with extremely wide dynamic range, excellent linearity and exceptionally low noise.

Sign up to our newsletter here

QHYCCD designs and manufactures high-performance scientific grade CMOS and CCD cameras. The QHY line of products include thermoelectrically cooled cameras, high- resolution scientific grade cameras, astronomical imaging cameras, digital X-ray machine DR cameras,. QSI entered the astronomical imaging field around 2007‐8 with a moderate range of cameras which included the QSI583 version 1. Both the QSI583 and QSI683 both employ the KAF8300 sensor (made by Truesense Imaging) with is roughly an APS size sensor.



Overall this camera was an unexpected surprise. CMOS technology has really come on leaps and bounds in recent years and this is great news for the consumer. Its capability and performance go far beyond its modest price tag and when all factors are taken into account it is quite possibly the best camera presently available to those interested in. Save qsi camera to get e-mail alerts and updates on your eBay Feed. + 7 S 0 P O N S O A R P A 7 E E D -1 -1 U J -1 0 F J -1 -1 Stealth Cam QSI24NGK Game Camera Kit 12 MP Infrared /Batteries /16gb SD card.

Design and manufacture world-class scientific cameras for applications that require superior imaging performance such as astronomical, life science, research and industrial imaging.

offer exceptionally well integrated technology for ease of use as well as minimal backfocus.

As the world continues to tackle the COVID pandemic, alongside adapting to the UK’s departure from the EU,… Read more »

As 2020 draws to an end, we can all agree there hasn’t been a year quite like it…. Read more »

Qsi Cameras Uk

We are pleased to announce that one of our software partners, Sequence Generator Pro (SGP), is producing an… Read more »

View all Articles

“No CCD sensor in recent memory has generated as much excitement as the 8.3mp Kodak KAF-8300 with tiny 5.4 micron pixels. All the major manufacturers of astronomical CCD cameras offer models with this detector, but those from Quantum Scientific Imaging caught our eye, because the built-in filter wheel is so close to the sensor that it works with standard 1 1/4″ filters. This can save hundreds of dollars compared to cameras that use external filter wheels and, by necessity, larger filters.”

Quantum Scienfic Instruments (QSI) is an imaging company which produces cameras primarily for scienfic imaging. They are based in the United States of America in Southern Mississippi.

Their main customers are those in the scienfic community with typical uses of imaging for life science, research and industrial imaging. QSI entered the astronomical imaging field around 2007‐8 with a moderate range of cameras which included the QSI583 version 1. Both the QSI583 and QSI683 both employ the KAF8300 sensor (made by Truesense Imaging) with is roughly an APS size sensor. The sensor has a moderate noise level with pixels at 5.4um and 8.3 megapixels in total.

I have owned a Quantum Scienfic Instruments (QSI) camera since 2009. I inially purchased a QSI583 and have subsequently acquired a QSI683. Both models were the WSG versions which incorporated a filter wheel and integrated guide port. My two main reasons for buying the 683 were the greater cooling power of the new model and the larger filter wheel. The 683 WSG‐8 cameras can cool to ‐45C from ambient and it can hold 8 filters, which allows a full complement of broad band and narrow band filters. Other bonuses are faster downloads of frames from the camera with USB2 compliance and 16 bit output.

The build quality of these cameras is immediately evident upon opening the pelican case in which it is housed and transported. The camera comes with a blue and black anodised aluminium body and is roughly the size of a CD without the filter wheel installed. With the filter wheel installed the camera is about twice the width of a CD, which makes it a small camera with compact features. When you pick it up it has a solid construcon feel to the camera. Nothing appears flimsy at all and you instantly feel as though you have bought a quality product.

There are a number of strengths these cameras have over other cameras on the market. The elegance of the guide camera port is not to be underesmated. The port allows guiding in front of the filters. Previous cameras on the market either did not have an integrated guide port or they had a guide camera behind the filters. The reason for having an integrated guide port or guide camera is to eliminate differenal flexure occurring when doing long exposures. Having the guide port in front of the filters means that guide star selecon will not be affected by filters transparency. The filter wheel mechanism is very innovave and so well integrated into the camera that only 1.25” filters are required to image in front of the KAF8300 sensor. The filter wheel rotaon is very accurate and I have never seen any problems with correct alignment.

The camera is very light. Many astronomical cameras in the past have been quite heavy. This can be disadvantageous for a number of reasons ranging from weight restricons of your mount or even having the ability to balance your telescope on the mount.

Qsi Camera Control Software

However these cameras do have a few short comings. The main problem I have with this camera is the cooling delta. Being only able to only cool to ‐45C from ambient can mean you are limited to actually cooling to ‐20C on the sensor most nights. It would be preferable to image at ‐30C on the sensor but this is only possible in the winter months in South Australia. Deeper cooling would mean reduced noise in the sub exposures and reduced integraon me for many objects.

When you buy this camera you have to be prepared to buy a guide camera. They don’t come with a guide camera in the package. This can mean you are going to spend at least another $500 more to use the camera.

Overall, though, this camera is a real winner in my opinion. It cks a lot of boxes and it has proven to be very reliable, in fact I think is very “bullet proof”. I have asked a lot of it and it has delivered every me. It works perfectly in automated environments and for many hours at a me. It has helped me produce a lot of images over the last 4 years and I have done over ten thousand sub frames with this camera and I expect it to do many more in the years to come. It has never broken down and integrates well with many soware programmes. It you’re looking for a recommendaon for a camera, this one has my stamp of approval.

Qsy Cameras

See many of Paul’s pictures with this camera at www.paulhaese.net
